Giant Door is resistant
Dual panels gathered and folded on both sides
High tensile strength and resistance to tearing
Panel made of PVC + paint coated Poly Panama fabric
Structure in high strength steel trusses
Perfect thermal and acoustic insulation
Perfect seal against external agents
Giant Door is big
Able to close rooms of large dimensions
Available in different measurements for different space requirements
Dimensions: 20/40 m base x 10/20 m height
Giant Door is functional
High opening speed (about .2-.3 m/sec)
Structure in high strength steel trusses
Excellent resistance to wind pressure (about 150 km/h)
High thermal-acoustic insulation
Minimum space required in folded position
Giant Door is customizable
Number of spars customizable Opening speed on request according to the width
Customizable dimensions
Realization in all standard colors Personalization with customer’s company logo
Giant Door is safe
CE compliance
Double flashing motion light
“Dead man” safety switch
Infrared photoelectric cells
Parachute brake system to prevent the falling of the dual panels
Compliance with Directive 89/106 / EEC of law EN 133241-1: 2003 and essential requirements of the Machinery Directive 98/37/EC
